9002 glass beads
- Brand Name: Junda
- Place of Origin: Shandong, China
- Standard: Japanese standard :JISR3301
- Payment Terms: L/C,T/T
Product Detail
Glass beads are the main points of contact where energy from the mill is transferred to the pigment particles, causing reduction in their size. Since the Glass beads are the actual perpetrators of attrition on the pigment particles, by increasing the number of beads or points of contact in the mill one will increase the opportunity for collision and shearing between the bead and the pigment particle.
The ability to operate a mill with smaller-diameter grinding media greatly increases the mill's efficiency and can overall further increase the quality of product through finer grinding. However, smaller Glass beads are more prone to hydraulic packing due to their decrease in mass per bead. Hydraulic packing occurs when the drag flow from the product pulls the media with the product and ultimately causes media packing around the discharge screen.
| Project | Quality | |
| Chemical composition% | SiO2 | >72% |
| CaO | >8% | |
| Na2O | <14% | |
| MgO | >2.5% | |
| Al2O3 | 0.5-2.0% | |
| Fe2O3 | 0.15% | |
| Others | 2.0% | |
| Refractive Index | Nd≥1.5% | |
| Density | 2.4-2.6g/cm3 | |
| Size distribution | Oversize ≤5% under size ≤10% | |
| Wire diameter | 0.03-0.4mm | |
| Durability | 3-5 % | |
| Hardness | 6-7 MOHS ;46HRC | |
| Microhardness | ≥650kg/cm3 | |
| Circularity | Round rate of ≥95% | |
| Appearance | colorless ,glass transparent without impurities,Round and smooth | |
| Application | 1.Grinding 2.Road marking paint 3.Sand blasting | |
| Lead Content | No lead content, reach American 16CFR 1303 Lead content standard | |
| Harmful substances content | Lower than American 16CFR 1500 standard | |
| Flammable fire test | Not easy combustion,reach American 16CFR 1500.44 standard | |
| Soluble heavy metal content | Metal content of soluble matter ratio solid weight rate no more than ASTM F963 corresponding value | |
| Package | 25KG/pp bag then 40 bags in one ton bag/pallet | |
| Type | Mesh | Micronsm Max(μm) | Microns Min(μm) |
| 30# | 20-40 | 850 | 425 |
| 40# | 30-40 | 600 | 425 |
| 60# | 40-60 | 425 | 300 |
| 80# | 60-100 | 300 | 150 |
| 100# | 70-140 | 212 | 106 |
| 120# | 100-140 | 150 | 106 |
| 150# | 100-200 | 150 | 75 |
| 180# | 140-200 | 106 | 75 |
| 220# | 140-270 | 106 | 53 |
| 280# | 200-325 | 75 | 45 |
| 320# | >325 | 45 | 25 |
Packaging & Delivery
Packaging Details Glass beads :
1 25kg/pp(paper) bag ,then 40 bags in one ton bag.
2 25 kg/pp(paper)bag, then 40 bags on one pallet
3 25 kg/pp(paper)bag, then 40 bags in one box
4 one ton one bag
Or as customers requirement.
Delivery Time glass beads
3-5 work days after get your advanced payment
